Clear polycarbonate roofing sheets
Clear polycarbonate roofing sheets profiled to match R/W 1000, SL 940, Delta 3/5, Kappa 3/5 and Lithos 5, so natural light goes in the same run as the panels. Compact or cellular sheets, modular joint systems for large translucent roofs, and dome rooflights with optional roof-access hatch. [Confirm the client will supply these]
Compact polycarbonate
Width 2050 standard, up to 2500 mm. ≈50% of the weight of glass at equal thickness. UV and non-UV versions.
Cellular polycarbonate
Sheets 1250 × 6000 and 2100 × 6000 mm. Service temperature −40 °C to +120 °C. Fire reaction EN 13501 B-s2,d0. UV co-extruded.
Rooflights
Metal base with shaped cellular polycarbonate dome; manhole version with telescopic opening to 70° (700 × 700 mm) for roof access. Suits Delta 3, Delta 5, R/W 1000. Colours: White grey, dark brown, Siena red.
Clear polycarbonate roofing sheets questions
Compact or cellular polycarbonate?
Compact is a single solid sheet, up to 2500 mm wide, half the weight of glass. Cellular (multiwall) traps air for insulation and is fire-rated B-s2,d0.
Can rooflights match my panel profile?
Yes. Profiled polycarbonate is made to the same rib as the panel or sheet, and dome rooflights are supplied to suit Delta 3, Delta 5 and R/W 1000.
