Alfa 1
Insulated wall panel, visible fixing · micro-ribbed, 166.4 mm module · 25–200 mm · PUR / PIR
B-s2,d0
View Alfa 1 Insulated wall panels & cladding
Insulated wall panels and insulated cladding from 25 to 200 mm, with a visible fixing (Alfa 1, Alfa 2) or a hidden joint (Star, Wall Design, Onda), plus the Airfix ventilated facade system. PIR cores reach B-s1,d0 and EI30 from 100 mm.
6products
0.11W/m²K at 200 mm
EI30Alfa 2 from 100 mm
All insulated wall panels products
Alfa 2
Insulated wall panel, visible fixing · alternative surface finish to Alfa 1 · 25–200 mm · PUR / PIR
B-s1,d0EI30
View Alfa 2
Wall Design
Architectural wall panel, hidden fixing · concealed fix, designed for horizontal installation (bottom-up) · 40–160 mm · PUR / PIR
B-s1,d0
View Wall Design
Airfix
Ventilated facade panel system · trapezoidal rib with clamp fixing for rainscreen (no through-drilling) · 30–140 mm · PUR / PIR
B-s1,d0
View Airfix Compare the range
Declared values from manufacturer datasheets to EN 14509 and EN 13501. A dash means no rating is published.
| Product | Type | Core | Thickness | U @ 100 mm | Reaction to fire | Fire resistance | External fire |
|---|---|---|---|---|---|---|---|
| Alfa 1 | Insulated wall panel, visible fixing | PUR / PIR | 25–200 mm | 0.22 | B-s2,d0 | – | – |
| Alfa 2 | Insulated wall panel, visible fixing | PUR / PIR | 25–200 mm | 0.22 | B-s1,d0 | EI30 | – |
| Star | Insulated wall panel, hidden fixing | PUR / PIR | 40–160 mm | 0.22 | B-s1,d0 | – | – |
| Wall Design | Architectural wall panel, hidden fixing | PUR / PIR | 40–160 mm | 0.22 | B-s1,d0 | – | – |
| Onda | Wave-profile wall panel, hidden fixing | PUR / PIR | 70–100 mm | 0.27 | B-s2,d0 | – | – |
| Airfix | Ventilated facade panel system | PUR / PIR | 30–140 mm | 0.22 | B-s1,d0 | – | – |
Which one do I need?
Not sure? Send us the span, the use and the county and we will spec it. No charge.
Get a quote- Workshop or shed walls, budget-led
- Alfa 1 or Alfa 2, visible fix, 40–80 mm
- Fire compartment wall
- Alfa 2 at 100 mm+ (B-s1,d0, EI30), or Fibermet mineral wool for EI120–EI180
- Clean lines, no visible screws
- Star (vertical) or Wall Design (horizontal), 40–160 mm
- Architectural facade or rainscreen
- Onda wave profile, or Airfix ventilated system
- Modular or prefab building
- Star or Wall Design, 60–100 mm
Facings and coatings
Pre-painted galvanised steel, Aluzinc, stainless steel or aluminium. Coatings: polyester, Superpolyester HD, PVDF, PUR/PA, Plastisol, plasticised PVC.
Certifications on this range
Reaction to fire (EN 13501-1), fire resistance (EN 13501-2), external fire (EN 13501-5), EPD type III and CE marking. Classes depend on core and thickness and are confirmed at order.
Full certification tablesInsulated wall panels & cladding questions
Visible or hidden fixing?
Visible-fix panels (Alfa 1, Alfa 2) are cheaper and faster; hidden-fix (Star, Wall Design) give a clean facade with no screw heads. Performance is the same at the same thickness.
Can wall panels be fitted horizontally?
Wall Design is made for horizontal, bottom-up installation. Alfa panels are designed for vertical installation; horizontal use needs a designer to check the joint.
